Searchlight SANSHIN ROBO RGL40E

SANSHIN LED remote controlled searchlight type ROBO - RGL40E

In addition to the conventional headlights (Xenon, Metal Halide and Halogen) we have developed an LED headlight.

We have adopted the Form module type. It is less sensitive to vibrations than conventional headlights.

Energy saving 1/6 (40W) compared to a halogen lamp. The maximum light intensity is more than that of a 300W halogen lamp (max. light intensity 380.00cd).

Long service life (approx. 40,000 hours)

TECHNICAL DATA:

• Luminous intensity-cd : 380,000 cd
• Tilt angle : 45°
• Climbing angle : 15°
• Power consumption : DC24V
• Rotation range : left and right 170°
• Tilt speed : approx. 3.8°/sec.
• Rotation speed : approx. 20°/sec.
• Focus setting : fixed
• Protection level : IP56
• Color : Mumsell N-9.5 (white)
• Control panel : CPF195
• Headlight dimensions (WxHxD): 375x457x241mm
• Weight : 13.0 kg
